UNOBOX…G - EC-Box fan
Supply air or extract air fans
- installation in any positions possible
- casing with two chambers aluminum profile
- discharge in any direction possible
- energy saving with EC motors
Description:
The Rosenberg EC-Unoboxes are designed to handle air volumes from 800 m³/h to 19.000 m³/h. Typical applications are in apartments, shops, supermarkets, repair shops, warehouses, garages etc. and other areas
of slight air contamination.
Application ares:
Garage / Offices / Bars / Greenhouses / Skyscrapers / Hotels / Industrial buildings / Basement rooms / Playschool / Cinemas / Parking facilities / Warehouses / Nursing homes / Schools / Sports halls / Supermarkets / Workshops / Residential houses / Fitness centers / Inflatables
Air Outlet:
Rosenberg Unoboxes are delivered with axial air flow direction through the casing. Should a different direction be required, this is easily possible by removing a side panel and mounting it to the front end.
Motors:
The EC motors used are characterized by a very high degree of efficiency, even in partial load ranges, as well as good controlling and regulation behavior. They are easy to connect, individually preconfigured, compact in design and show a high power density. The implementation of additional functions (e.g. air flow and pressure control) is possible. All motors are speed controllable in the range 0-100%.
Integrated Motor Protection:
The motor protection is integrated with Rosenberg EC motors. All necessary parameters, such as temperature, blocked rotor, over and undervoltage and power are continuously checked and monitored via an intelligent failure management.
Casing:
The housing supporting frames are double chamber aluminum profiles with corners made of plastic and double skinned (20mm) galvanized steel panels insulated with non-inflammable, noise and temperature insulating fiberglass mats. One side of the casing is open as standard.
